Reliable LNG Refueling Station Equipment Solutions
LNG Refueling Station Equipment represents a comprehensive, heavy-duty cryogenic fuel delivery ecosystem. Engineered to store and dispense liquefied natural gas, these solutions provide high-performance, fast-fill fuel refueling for long-distance freight trucks, municipal transit buses, heavy-duty logistics fleets, and maritime ships, driving the transition to sustainable industrial transport.
-
![Containerized LNG Refueling Station]()
Containerized LNG Refueling StationThe containerized LNG refueling station is a fully integrated, mobile cryogenic fueling system housed within a standard ISO container frame. -
![High-flow LNG Refueling Pump Skid]()
High-flow LNG Refueling Pump SkidThe High-flow LNG Refueling Pump Skid is a pre-assembled pumping system designed to transfer liquefied natural gas from storage tanks to refueling dispensers or mobile fueling systems. -
![Single Nozzle LNG Dispenser]()
Single Nozzle LNG DispenserThe Single Nozzle LNG Dispenser is a dedicated cryogenic fueling unit designed to transfer liquefied natural gas from station storage assets directly into heavy-duty commercial vehicles. -
![Intelligent Network Management System For CNG Gas Station]()
Intelligent Network Management System For CNG Gas StationThe Intelligent Network Management System for CNG Gas Stations is a centralized software and hardware-enabled platform designed to monitor, control, and optimize multiple compressed natural gas... -
![Vertical LNG Cryogenic Storage Tank]()
Vertical LNG Cryogenic Storage TankThe Vertical LNG Cryogenic Storage Tank is a fixed industrial vessel designed to store liquefied natural gas at extremely low temperatures, typically around -162°C. -
![LNG Filling Column]()
LNG Filling ColumnLNG Filling Column is a cryogenic fueling terminal designed for safe and accurate LNG transfer. It handles liquefied natural gas using insulated piping, precision flow measurement, and... -
![Dual-gun LNG Dispenser]()
Dual-gun LNG DispenserDual-Gun LNG Dispenser is a cryogenic fueling system designed for dispensing liquefied natural gas (LNG) to two vehicles simultaneously or independently. -
![Single-gun LNG Dispenser]()
Single-gun LNG DispenserSingle-Gun LNG Dispenser is a cryogenic fueling system designed for accurate LNG dispensing to vehicles. It handles liquefied natural gas using an electronic metering and control system with a... -
![Cryogenic Submerged Centrifugal Pump-immersed Type]()
Cryogenic Submerged Centrifugal Pump-immersed TypeCryogenic Submerged Centrifugal Pump – Immersed Type is a vertical, fully immersed centrifugal pump designed for LNG transfer and pressurization. The pump and motor operate submerged in cryogenic... -
![Skid-mounted LNG Refueling Device]()
Skid-mounted LNG Refueling DeviceSkid-Mounted LNG Refueling Device is a compact LNG fueling system integrating a cryogenic pump sump, submerged pump, dispenser, vaporizer, piping, and PLC controls. It transfers and dispenses... -
![LNG Fueling Pump Skid]()
LNG Fueling Pump SkidLNG Fueling Pump Skid is a skid-mounted LNG transfer and fueling system integrating a cryogenic submerged pump, vacuum pump sump, vaporizer, piping, valves, and control system. It handles... -
![Skid-mounted LNG refueling station]()
Skid-mounted LNG refueling stationOur Skid-mounted LNG refueling station integrates the cryogenic storage tank, submerged pump, vaporizers, pipelines, and PLC control system onto a single heavy-duty structural chassis.
Technical Specifications
|
Parameter |
|
|
Working medium |
LNG(Liquefied Natural Gas) |
|
Total volume of storagetank |
30m³(60m³) |
|
Heatinsulation of storagetan |
High vacuum pearlife padding |
|
NO.of pumps |
1unit(2units) |
|
Max.discharge of pump |
340L/min(680L/min) |
|
Operating pressure |
1.6Mpa |
|
Measurin gaccuracy |
±1.0% |
|
Pipeline design temperature |
-196℃ |
|
Total power |
20KW(35KW) |
|
Noise |
≤55dB |
|
Explosive-proofgrade |
ExdⅡBT4 |
|
Control mode |
PLC full automatic control |
Advanced Cryogenic Thermal Insulation: Tanks utilize high-vacuum pearlite padding insulation, restricting the daily static vaporization rate to under 0.3% to minimize Boil-Off Gas (BOG).
Zero-Emission Vapor Recovery: Integrated vacuum-jacketed pipelines, cryogenic valves, and specialized BOG heaters optimize pressure dynamics and safely recover low-temperature flash gas.
Modular Fast-Deploying Architecture: Pre-engineered skid-mounted and containerized structures reduce civil construction costs, accelerate project lead times, and facilitate rapid mobilization.
Product Categories
Integrated Refueling Stations & Platforms
LNG Refueling Station: Standard comprehensive cryogenic refueling terminal utilizing high-vacuum insulation technology to provide reliable high-volume vehicle fueling.
LNG Refueling Station (Alternative Standard Spelling): Turnkey cryogenic fueling infrastructure compliant with international standards, offering optimized fluid logistics.
LNG Fuel Stations: Commercial-grade alternative fuel hubs designed for heavy-duty logistics and high-frequency long-haul fleet charging.
Skid-mounted LNG refueling station: Fully pre-assembled, factory-tested structural skid solution for minimized on-site civil works and immediate plug-and-play field deployment.
Skid-mounted LNG Refueling Device: High-integrity compact process skid integrating cryogenic pumping, filtration, and process controls on a heavy-duty base frame.
Containerized LNG Refueling Station: Secure, weather-proof ISO container-enclosed station design built for remote logistics routes and extreme ambient protection.
LNG All-in-one Filling Station: Highly compact, space-optimized refueling architecture combining storage and dispensing loops for restricted industrial locations.
Cryogenic Storage Systems
Vertical LNG Cryogenic Storage Tank: Space-saving vertical pressure vessel featuring high-vacuum pearlite padding to restrict static vaporization to under 0.3%.
LNG Refueling Station (LNG Vertical Storage Tank): Vertical tank-based fueling station configuration engineered for municipal urban gates and footprint-constrained fleet yards.
LNG Refueling Station (LNG Horizontal Storage Tank): Symmetrical horizontal tank-based refueling system offering a low center of gravity and high liquid volume retention.
Cryogenic Pumping & Boosting Skids
Cryogenic Submerged Centrifugal Pump-immersed Type: Zero-leakage sump-submerged pump loop providing instantaneous cold start-ups without gas cavitation risks.
High-flow LNG Refueling Pump Skid: High-capacity process skid delivering optimized flow rates up to 680 L/min for massive fleet and maritime refueling.
LNG Fueling Pump Skid: Heavy-duty liquid transfer module with active pressure-boosting controls to supply high-pressure cryogenic liquid to dispensers.
Precision Dispensing Infrastructure
Single-gun LNG Dispenser: Premium single-hose dispenser equipped with breakaway couplings, grounding safety circuits, and digital custody transfer computers.
Single Nozzle LNG Dispenser: High-precision retail fuel terminal featuring advanced mass flow meters for accurate custody transfer and billing.
Dual-gun LNG Dispenser: Multi-hose high-throughput refueling device allowing simultaneous, independent fueling of two logistics trucks.
LNG Filling Column: Rugged industrial fueling post optimized for fast-fill commercial terminal layouts and heavy transport yards.
Advanced Automation & Station Networks
Intelligent Network Management System For CNG Gas Station: Centralized PLC automation software overseeing safety interlocks, tank inventory tracking, and electronic transaction metrics for hybrid CNG/LNG grids.
Custom Engineering Capabilities
Peak-Shaving Vaporization Backups: Ambient air vaporizers and water bath trim heaters can be configured at a 1.3 to 1.5× surge factor to manage high-volume utility or fleet demands during low ambient temperatures (<5℃).
Flexible Pressurization Engineering: Customizable configurations utilizing dedicated self-pressurizing vaporizers to accelerate tanker unloading and station storage tank pressure management.
Why Choose Us
500+ Global Energy Projects
A proven global track record of delivering turnkey gas processing and energy station infrastructure across 50+ countries in Europe, Asia, and the Americas.
100+ Core Energy Patents
Continuous R&D investment in hydrogen safety, high-pressure automation control, and advanced gas separation technologies.
Tier-1 Quality Management
Globally certified under ISO 9001, ISO 14001, and ISO 45001 systems, with full materials and welding traceability for heavy industrial compliance.
Packaging & Delivery
Pre-Assembled Skid Delivery
Systems are delivered as fully pre-wired, pre-tested, containerized, or skid-mounted modules to drastically reduce on-site civil works and commissioning times.
Global Field Services
Provides on-site installation supervision, mechanical and electrical commissioning, SAT (Site Acceptance Testing), and specialized operator safety training.
Standard Project Lead Time
8–12 weeks (depending on system complexity, compressor displacement ratings, and procurement cycles of long-lead pressure components).
FAQ
With abundant experience, we are one of the most professional LNG refueling station equipment manufacturers in China. Please feel free to buy high quality LNG refueling station equipment for sale here from our factory. Also, customized service is available.
